Key Features:

• Dual Socket P (LGA 3647) support
  2nd Gen Intel® Xeon® Scalable
  processors (Cascade Lake/Skylake)
• 12 DIMMs; up to 3TB 3DS ECC
  DDR4-2933MHz
• Expansion slots: 1 PCI-E 3.0 x16 (LP)
  1 PCI-E 3.0 x16 (for SIOM )
• 6 Hot-swap 2.5" SAS3/SATA3 or 2
  Hot-swap 2.5" SAS3/SATA3 +
  4 optional NVMe U.2
  M.2 Interface: PCI-E 3.0 x4
  M.2 Form Factor: 2260, 2280, 22110
  M.2 Key: M-Key
• SAS3 via Broadcom 3008
• SIOM Network card,
  1 dedicated IPMI LAN port
• 1 VGA, 2 USB 3.0 ports
• 3x 4cm 20k RPM middle fans
• 2200W Redundant Power Supplies
  Titanium Level (96% Efficiency)
