SSG-5049P-E1CTR36L

  • Connectivity/Storage Compute Nodes
  • Database Processing Appliance Platform
Intel
4 HE
1 CPU
8 DIMMs
36 Drives
2 x 10 GbE
Red. PSU
NVMe (optional)
SAS (native)
Key Features:
  • Single Socket P (LGA 3647) supports
    2nd Gen Intel® Xeon® Scalable
    processor (Cascade Lake/Skylake)
  • 8 DIMMs; up to 2TB 3DS ECC
    DDR4-2933MHz
  • 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8,
    1 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8)
  • 2x 10GBase-T with Intel® X557
  • 36 Hot-swap 3.5" SAS/SATA drive bays
    with SES3 (24 front + 12 rear);
    2 Internal fixed bay support up to
    4x 2.5" drive bays (optional)
    4 Internal fixed 2.5" drive bays
    2 Hot-swap 2.5" NVMe/SATA
    (rear, optional)
  • SAS3 via Broadcom 3008 controller
  • Server remote management: IPMI 2.0
    / KVM over LAN / Media over LAN
  • 7 High-performance 8cm PWM fans
  • 1200W Redundant Power Supplies
    Titanium Level (96%)
